馬達: | Single phase induction capacitor motor, thermally protected or impedance protected |
外殼: | Die-cast aluminum, Painted black (AP) or Plated (AN) |
風葉: | Glass reinforced thermoplastic, UL 94V-0 |
軸承: | Two-ball bearing |
接電方式: | T-Terminal push-on type or W-Lead wire type |
耐壓: | 1 min. at 1,500VAC, 50/60Hz |
溫度範圍: | Ambient -20℃~+70℃ |
壽命: |
60,000 hours at 25℃ 40,000 hours at 65℃ |
淨重: | 2.88 kg |
檢定: | UL, CUL, TUV, CE, RoHS |
型號 | 電壓 | 頻率 | 電流 | 功率 | 轉速 | 最大風量 | 最大風壓 | 噪音 | ||
m3/min | CFM | mm-H2O | inch-H2O | |||||||
SK225AP-11-1 |
110 (110V~120V) |
50/60 | 0.98/0.90 | 78/98 | 2920/3450 | 17.8/21.2 | 630/750 | 30/40 | 1.18/1.57 | 63/67 |
SK225AP-22-1 |
220 (220V~240V) |
50/60 | 0.45/0.45 | 88/105 | 2920/3450 | 17.8/21.2 | 630/750 | 30/40 | 1.18/1.57 | 63/67 |
